SPL De-Esser Model 9629

More Views

  • SPL De-Esser Model 9629

SPL De-Esser Model 9629

Be the first to review this product

2-Channel, "one-knob" de-esser, auto threshold, male/female function

Availability: In stock



Contact us for more information about this product.


Product Description


SPL De-Esser Model 9629 2 Channel 1 Knob De-Esser Auto Threshold


The SPL Auto-Dynamic De-Esser is a highly specialized audio tool for removing undesired sibilant frequencies in a very simple and musical way without compromising the timbre and natural character of a voice. To solve this difficult problem, SPL has developed a new circuit design that combines ease of use with natural sound characteristics and the highest level of technical performance. SPL's Auto Dynamic De-Esser monitors the S-frequency spectrum and automatically detects the sibilant frequencies. The de-ess bandwidth is set so narrowly around the range of the sibilance that neighboring frequencies remain unaffected. Input processed via this frequency band is mixed back into the main signal phase-inverted so that only the S-sounds are canceled where the S-reduction controller determines the intensity of the phase-canceled mix. The result is a neutral, unobtrusive and extremely effective de-essing process. Even at high S-reduction values the de-essing has a negligible effect on the character and timbre of the voice. Rounding out the amazingly simple control system is an automatic threshold-adjusting function. Differences in the input level caused by the varying distance to the mic, are compensated for automatically. This ensures even De-Essing independent of signal level so any necessary compression may be applied post the de-esser.

Inputs and outputs:

  • Instrumentation amplifier,electronically balanced (differential),transformerless
  • Nominal input level +6 dB
  • Input impedance =22 kOhm
  • Output impedance < 600 Ohm
  • Max. input level +24 dBu
  • Max. output level +22.4 dBu
  • Minimum load 600 Ohm
  • Relay hard bypass / power fail safety


Measured data

  • Frequency response 20 Hz-50 kHz (50kHz= -3dB)
  • Common mode rejection > -80 dBu @1kHz
  • Total harmonic distortion 0.002% @ 1 kHz
  • Signal-to-noise ratio -93 dBu (CCIR 468-3)
  • Signal-to-noise ratio -98 dBu (A-weighted)


Power supply

  • Toroidal transformer 15 VA
  • Fuses (230/115 V) 315 mA/630 mA
  • GND lift switch, voltage selection switch 115 V / 230V



  • Standard EIA 19"/IHE 482 x 44 x 237mm
  • Weight 3.4 kg
  • Note: 0 dBu = 0.775 V

Additional Information

Additional Information

Manufacturer SPL
Condition New
Model 9629
Type Deesser
Features Solid State
Form Factor 1 RU
Effect/Enhancement Deesser
Number of Channels 2
Connectivity TRS 1/4, XLR
Inputs/Outputs N/A
